80-96 4WD F150 Long Travel Kit (Extended Width) Front Only
-
Fast Shipping
-
Made in the USA
This Extended Width Long Travel kit provides 18” of wheel travel and will clear a 35 or 37” tire. The beams are extended +4.5" on each side and corrected camber corrected for increased ride height. Plating and uniballs are then installed for reinforcement and provide better articulation as the beam cycles through its travel. Since the front track width has been increased, new extended inner axle shafts are included to accommodate for the wider suspension. A mild drop pitman arm is provided to correct steering geometry. King's 2.5x12” coil over shocks provide superior dampening with our spec'd valving and bolt into place using our front shock hoop system. Also included are new alignment cams, stainless steel extended brake lines, and limit straps. Every kit comes standard with our bestselling High Clearance radius arms and Steel Tube Engine Cross Over, however option to upgrade to our new Billet Aluminum radius arms and engine cross over is now available. Upgrading coil overs to internal bypass with compression adjusters or 3.0 diameter shock also available.
Note: Professional install is highly recommended to ensure optimum performance and safety. This kit requires fiberglass fenders and welding to install shock hoop/engine crossover. All vehicles require alignment after lift install. Beam core charge of $500 is included in price. If you supply us with a core in good condition we are happy to issue a refund for the core charge.
Features:
- 3-5” of lift
- Provides 18” of travel
- Better front end articulation
- TTB Plating and Uniball Pivots
- Track width increase of 9"
- High performance coil over suspension
- Front shock configuration fits up to a 3.0x12" coil over
- Coil overs include Desolate Motorsports spec'd valving
- Clears up to 37” tire
